TP-LINK ROUTER Router (Ethernet) Wi-Fi N300

MW305R
Router Wireless N 300Mbps

• Velocità wireless fino a 300Mbps, perfetto per streaming video HD, gaming online e download
• 3 antenne 5dBi per una copertura wireless stabile ed estesa
• Installazione semplice - guida web intuitiva per configurare il Router in pochi istanti





Wireless

Wireless Standards

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Frequency

2.4 - 2.4835GHz

Signal Rate

11n: Up to 300Mbps (Dynamic)

11g: Up to 54Mbps (Dynamic)

11b: Up to 11Mbps (Dynamic)

Reception Sensitivity

270M: -70dBm@10% PER

130M: -74dBm@10% PER

108M: -74dBm@10% PER

54M: -77dBm@10% PER

11M: -87dBm@8% PER

6M: -90dBm@10% PER

1M: -98dBm@8% PER

Transmission Power

<20dBm

Wireless Security

64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK

Wireless Functions

WDS bridge





Software

WAN Type

Dynamic IP/Static IP/PPPoE/L2TP/PPTP

Management

Parental Control

Access control

Local management

Remote management

DHCP

Server

Port Forwarding

Virtual server, UPnP, DMZ

Dynamic DNS

DynDNS?NO-IP

Firewall Security

IP and MAC address binding

Protocols

IPv4

Guest Network

2.4GHz guest network



Hardware

Dimensioni (W X D X H)

169 x 116 x 35 mm

Interfaces

3 10/100Mbps LAN ports

1 10/100Mbps WAN port

Button

Reset/WPS button

External Power Supply

5VDC/0.6A

Tipologia di Antenna

3 x 5dBi fixed omni directional antennas





Other

Certifications

CE, ROHS

Package Contents

300Mbps Wireless N Router

MW305R

Power adapter

Quick installation guide
Ethernet cable



Environment

Operating temperature: 0°C ~ 40°C (32°F ~ 104°F)

Storage temperature: -40°C ~ 70°C (-40°F ~ 158°F)

Operating humidity: 10% ~ 90%, non-condensing

Storage humidity: 5% ~ 90%, non-condensing

WIRELESS
Standards and ProtocolsWi-Fi 4
IEEE 802.11n/b/g 2.4 GHz
WiFi SpeedsN300
2.4 GHz: 300 Mbps (802.11n)
WiFi RangeCase di piccole dimensioni
2× Antenne fisse
WiFi CapacityBase
Working ModesModalità Router
Modalità Access Point
Modalità Range Extender
Modalità WISP

SICUREZZA
Network SecuritySPI Firewall
Controllo accessi
IP & MAC Binding
Application Layer Gateway
Guest Network1× Rete Ospiti 2.4 GHz
WiFi EncryptionWEP
WPA
WPA2
WPA/WPA2-Enterprise (802.1x)

HARDWARE
ProcessorSingle-Core CPU
Ethernet Ports1× Porta WAN 10/100 Mbps
4× Porte LAN 10/100 Mbps
ButtonsTasto Reset
Power9 V ? 0.6 A

SOFTWARE
ProtocolsIPv4
IPv6
Parental ControlsFiltro URL
Limiti di tempo
WAN TypesIP Dinamico
IP Statico
PPPoE
PPTP
L2TP
Quality of ServiceQoS per dispositivo
NAT ForwardingPort Forwarding
Port Triggering
DMZ
UPnP
IPTVIGMP Proxy
IGMP Snooping
DHCPRiserva Indirizzi
Lista Client DHCP
Server
DDNSNO-IP
Comex
DynDNS
Management FeaturesTether App
Pagina Web
Simulatore web>

OTHER
Network Services Enabled by DefaultWeb Server
Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443 Protocol: TCP
DHCP Server
IP address assignment (DHCP)
• Port: 67 Protocol: UDP
App management
Manage and configure device through app
• Port: 22 Protocol: TCP
• Port: 20001 Protocol: TCP
• Port: 20002 Protocol: UDP
System RequirementsInternet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, o altri browser che supportano JavaScript

Cable o DSL Modem (se necessario)

Abbonamento con un Service Provider per l'accesso a Internet
CertificationsFCC, CE, RoHS
EnvironmentTemperatura di Funzionamento: 0?~40? (32? ~104?)
Temperatura di Stoccaggio: -40?~70? (-40? ~158?)
Umidità di Funzionamento: 10%~90% senza condensa
Umidità di Stoccaggio: 5%~90% senza condensa
TEST DATA

WiFi Transmission PowerCE:
<20dBm(2.4GHz)
FCC:
<30dBm
WiFi Reception Sensitivity270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
PHYSICAL

Dimensions (W×D×H)7.2 × 5.0 × 1.4 in
(182 × 128 × 35 mm)
Package ContentWi-Fi Router TL-WR840N
Alimentatore
Cavo Ethernet RJ45
Guida rapida all'installazione
